Hdpe Pipe Manufacturing Machine Pipe Extrusion Machine Plastic Pipe Extruder
Double wall corrugated pipe extrusion machine dwc pipe manufacturing machine water drainage system
hdpe pvc single double wall corrugated drain pipe machine production line extruder extrusion
Double Wall Corrugated Hdpe Pipe Machine With High Qualify Mold And Forming Machine
Manufacturer Sn8 Black Hdpe Double Wall Corrugated Tube PE Sewerage Hdpe Tube Drainage System Plastic Corrugate Pipe extrusion machine
HDPE/PVC Double Wall Corrugated Pipe Making Machine
Double Wall Corrugated Pipe Production Line
PE/HDPE/PVC double wall corrugated pipe extrusion line adopts extruding and forming process, it has the featuresof reliable quality and high efficiency.Compared with other plastic pipe wall structure ,double wall corrugated pipe has excellent wall structure design,its low weight reach the lower production cost and improve the market competitiveness.The pipe is widely used in various field instead of concrete pipe and iron pipes,because it has excellent features such as:easy connected and accessories installed,and quality reliable.
Production Line Machine List |
| NO. | Machine Item | QTY |
| 1 | single screw extruder | 2 sets |
| 2 | Co-Extrusion Die head mold | 1 set |
| 3 | Forming machine with air and water cooling type | 1 set |
| 4 | Automatic double station winding machine | 1 set |
| Extruder moudle | Motor | Pipe diameter | Production speed | Mould pairs | (optional)Vacuum pump |
| SJ65/30&SJ50/30 | 30KW&15KW | 32-50mm | 4-5m/min | 72 pairs | 7.5kw |
| SJ65/33&SJ65/30 | 37KW&30KW | 50-110mm | 3-5m/min | 38pairs | 7.5kw |
| SJ65/33&SJ65/30 | 45KW&37KW | 50-160mm | 2-3.5m/min | 38pairs | 75.5kw |
| SJ75/30&SJ65/30 | 55KW&45KW | 110-200mm | 2-5m/min | 38pairs | 75.5kw*2set |
HDPE/PP/PVC Pipe/Tube/Double Wall Corrugated/Extrusion Line Producing Machine
50-160mm HDPE double wall corrugated pipe DWC tube making machine manufacture
Product Application
HDPE double wall corrugated pipe making machine
HDPE and LDPE double wall corrugated pipe machine line Plastic Pipe Etruder Machine
Supply gas and water supply PVC HDPE double pipe machine Double wall corrugated pipe making machine
HDPE/PVC Double Wall Corrugated Pipe Machine
Brief introduction of double wall corrugated pipe machine:
PVC PE double wall corrugated pipe machine/extrusion line adopts extruding and forming process, has the features of reliable quality and high efficiency. Compared with other plastic pipe wall structure, double wall corrugated pipe has excellent wall structure design, its low weight reach the lower production cost and improve the market competitiveness.
It is widely used in various field instead of concrete pipe and iron pipes, because it has excellent features such as: easy connected and accessories installed, and quality reliable.
pipe production machine for waste water
Features.
1. High toughness and good seismic performance;
2. The connection is reliable;
3. Low density, light weight, easy to handle and install
4. Can resist a variety of chemical media corrosion;
5. Excellent hydraulic performance, the wear resistance coefficient is only 0.009;
6. Long service life, up to 50 years;
7. Good hygiene and environmental performance;
8. Better resistance to slow crack growth (SCG) and rapid crack propagation (RCP).
HDPE double wall corrugated pipe
High Density Polyethylene (HDPE) Double Wall Corrugated Sewer and Drainage Pipes are for gravity and low pressure sewerage and
drainage such as waste water, sanitary sewer and storm sewerage for municipal or industrial use. The pipes provide important
Specification:
Size: DN200 to DN800.
Ring stiffness: SN4, SN8.
Connection: Socket with rubber ring.
Length: 6 Meters/piece.
Application:
Sewer and drainage
drains for terrace and other residential units in housing schemes
Perimeter drains for commercial, industrial units and individual factories
As collector drains in subsoil system in road, highway, open field, stadium, retaining wall or parking space
As collector drains in subsoil system, sewerage treatment plant sludge drying bed under drains
corrugated pipe is mainly used for water drainage system. It is a fully computer controlled line. It features high and stable output capacity, and highly automatic operation. For HDPE, you can choose high efficient single screw extruder. For PVC, you can choose conical twin-screw extruder or parallel twin- screw extruder. Forming system consists mould and corrugator.
Mould blocks can be easily changed and they have air or water cooling system.
Product Tags:
|
|
Double Wall Corrugated Pipe Extrusion Machine , 50mm-160mm HDPE Pipe Manufacturing Machine Images
|
